Graco XM Series Repair Parts

Parts
66 313289W
XM_ P _ _ Parts Varying by Top-Level Part Number
See Models, page 9, for components equipped on your system.
Model Part Description For additional information, refer to:
XM1P00
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM1P10
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM1P20
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM3P00
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM3P10
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM3P20
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM5P00
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM5P0E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5P0W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOSE, heated, wat, 240V-H
Water-Jacketed Heated Hose, page 93
XM5P10
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM5P1E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5P1W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 240V-H
Water-Jacketed Heated Hose, page 93
XM5P20
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM5P2E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
XM7_ _ _ Models, page 81
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5P2W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
- - - HOSE, heated, wat, 240V-H
Water-Jacketed Heated Hose, page 93
XM7P00
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
XM7P0E
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HEATER, haz-ex, 240 V
Primary Fluid Heater Parts, page 90
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
