15
12. Serial port RS-232
The Z3 weight indicator can be connected to other devices to send and
receive information via an RS-232 interface. The connection is made using
the 3-pin MMC connector on the weight indicator chassis.
In this menu, it is possible to configure the different data transmission
options from the indicator.
It allows the speed to be selected at which the serial
interface will be connected. The possible options are:
9600 bauds, 19200 bauds, 38400 bauds, or 57600
bauds. Transmission format for each byte is 8 bits
without parity bit, 1 stop bit (“8,n,1”) and is not
configurable.
Mode in which the data frame transmission will be
made:
When pressing the print key.
Continuously, at a rate of 5 frames sent per
second.
Automatically every time there is a new
stable weight on the scale.
