Gram Z3 Series User Manual

27
18 Characteristics of the Z3 indicator
Load cell connection
Maximum input signal
±4 mV/V
Maximum input voltage
±
5.3 V
Internal resolution
AD 20bits converter, 1000000
counts (100000 external)
Measurement frequency
Maximum 80 samples per second
Linearity error
≤0.01% of the measurement range
Exciting voltage
5 Vdc
Minimum transducer impedance
95 Ω (4 cells x 380 Ω)
Cable length
30 m/mm
2
max. (6 wires)
User interface
Main indicator
5 LCD digits 25.4 mm in height.
Backlit with panel backlight
Keypad
4
-
key keypad
Acoustic warning
Piezoelectric intermittent
-
sound mini
-
buzzer (2300±300 Hz y 85 dB)
Serial communications
Port Tx/Rx: (Port 1)
Two
-
way RS
-
232C
Transmission speed
9600, 19200, 38400, 57600
Number of bits and parity
8 bits, no
parity, 1 bit stop
Power
Network connection
Through 7.5V feeder; 1 A
Battery
6V
-
1.2AH;
Service time 15/48 hours depending on use.
Operating conditions and mechanical data
Operational temperature range
+5ºC/+35ºC
Size (mm)
200 x 100 x 70 (ABS version)
Weight (kg)
650 g including battery (ABS
version)
Assembly
Desktop
Optional: Swivel mount
wall/column
Tightness
IP
-
65
