GRP2600 Administration Guide
Version 1.0.5.15
P a g e | 36
CONFIGURATION GUIDE
This section describes the options in the phone’s Web GUI. As mentioned, you can log in as an
administrator or an end user.
• Status: Displays the Account status, Network status, and System Info of the phone.
• Account: To configure the SIP account.
• Settings: To configure call features, ring tone, audio control, LCD display, date and time, Web services,
XML applications, programmable keys etc.
• Network: To configure network settings.
• Maintenance: To configure web access, upgrading and provisioning, syslog, language settings, TR-
069, security etc.
• Directory: To manage Phonebook and LDAP.
Status Page Definitions
Table 9: Status Page Definitions
Status → Account Status
Account
Account index.
• For GRP2612/GRP2612P/GRP2612W: up to 2 SIP accounts
• For GRP2613: up to 3 SIP accounts
• For GRP2614: up to 4 SIP accounts
• For GRP2615: up to 5 SIP accounts
• For GRP2616: up to 6 SIP accounts
SIP User ID
Displays the configured SIP User ID for the account.
SIP Server
Displays the configured SIP Server address, URL or IP address, and port of
the SIP server.
SIP Registration
Displays SIP registration status for the SIP account, it will display Yes/No
with Green/Red background.
Status → Network Status
MAC Address
Global unique ID of device, in HEX format. The MAC address will be used
for provisioning and can be found on the label coming with original box and
on the label located on the back of the device.
IP Setting
The configured address type: DHCP, Static IP or PPPoE.
IPv4 Address
The IPv4 address obtained on the phone.
IPv6 Address
The IPv6 address obtained on the phone.
