BLF LED PATTERNS
Table 14: BLF LED Patterns
Pattern: Default
Pattern: Analog
Call’s state
Light Indication
Call’s state
Light Indication
Offline
Off
Offline
Off
Idle
Solid Green
Idle
Solid Green
Trying
Solid Red
Trying
Solid Red
Talking
Solid Red
Talking
Solid Red
Proceeding
Flashing Red
Proceeding
Solid Red
Incoming call
Flashing Red
Incoming call
Flashing Red
Pattern: Directional
Mode: Inverse
Call’s state
Light Indication
Call’s state
Light Indication
Offline
Off
Offline
Off
Idle
Solid Green
Idle
Solid Red
Trying
Flashing Green
Trying
Solid Green
Talking
Solid Red
Talking
Solid Green
Proceeding
(Initiator)
Flashing Green
Proceeding
Flashing Green
Proceeding
(Receiver)
Flashing Red
Incoming call
Flashing Green
Incoming call
Flashing Red
