GRP2600 Administration Guide
Version 1.0.5.15
P a g e | 83
left blank. Enter the LDAP Name/Number filter in the Value field.
For example: If users set MPK 1 as “LDAP Search” for “Account 1”, and
set filters:
Description -> ou=video,ou=SZ,dc=grandstream,dc=com
Value -> sn=Li
Since the Base for LDAP server configuration is
“dc=83randstream,dc=com”, “ou=video,ou=SZ” is added to narrow the
LDAP search scope. “sn=Li” is the example to filter the last name.
• Call Log
Select Account and enter account number in the Value field to access to
the Call Log of that selected account.
• Menu
Select this feature in order to display the Menu from the MPK buttons,
no field dis required for configuration.
• Information
Select this feature in order to display the Information popup to show the
firmware version, MAC address, IP address and IP Settings from the
MPK buttons, no field dis required for configuration.
• Message
Select this feature in order to display the Message menu from the MPK
buttons, no field dis required for configuration
Account
Selects the account to be used with specific softkey.
Description
Enters a label for softkey.
Value
Specifies value for softkey depending on the mode selected.
Settings → Programmable Keys → Call Screen Softkeys
Order (1 – 3)
Displays Idle Screen Softkeys index. (1 – 3)
Note: Make sure “Custom Softkey 1/2/3” are selected in [Custom Call
Screen Softkey Layout].
Call Screen Softkeys
Assigns a function to the corresponding Call Screen Softkeys.
• Speed Dial
Select the Account to dial from. And enter the Speed Dial number in the
Value field to be dialed.
• Speed Dial via active account
Similar to Speed Dial but it will dial based on the current active account.
For example, if the phone is offhook and account 2 is active, it will call
