Grandstream Networks GWN7000 Management & Provisioning

P a g e | 15
GWN7000 Controller
GWN76xx Wireless AP Management & Provisioning
• Wi-Fi: Please refer to the below table for Wi-Fi tab options:
Figure 12: Add a New Network Group -> Wi-Fi Settings
Table 3: Network Group -> Wi-Fi
Enable Wi-Fi
Check to enable Wi-Fi for the network group.
SSID
Set or modify the SSID name.
SSID Hidden
Select to hide SSID. SSID will not be visible when scanning for Wi-Fi, to
connect a device to hidden SSID, users need to specify SSID name and
authentication password manually.
Security Mode
Set the security mode for encryption, 5 options are available:
• WEP 64-bit: Using a static WEP key. The characters can only be 0-9 or
A-F with a length of 10, or printable ASCII characters with a length of 5.
• WEP 128-bit: Using static WEP key. Characters can only be 0-9 or A-F

Grandstream Networks GWN7000 Specifications

General

Brand	Grandstream Networks
Model	GWN7000
Category	Network Router
Language	English
