P a g e | 45
GXP21XX Administration Guide
1[2-9]xx[2-9]xxxxxx |- allows dialing to any US/Canada Number with 11
digits length;
011[2-9]x - allows international calls starting with 011;
[3469]11 - allows dialing special and emergency numbers 311, 411, 611
and 911.
Note: In some cases, where the user wishes to dial strings such as *123 to
activate voice mail or other applications provided by their service provider,
the * should be predefined inside the dial plan feature. An example dial plan
will be: { *x+ } which allows the user to dial * followed by any length of
numbers.
Call Log
Configures Call Log setting on the phone. You can log all calls, only log
incoming/outgoing calls (missed calls will not be logged), or disable call log.
The default setting is "Log All Calls".
Account Ring Tone
Allows users to configure the ringtone for the account. Users can choose
from different ringtones from the dropdown menu.
Note: User can also choose silent ring tone.
Match Incoming Caller
ID
Specifies matching rules with number, pattern or Alert Info text. When the
incoming caller ID or Alert Info matches the rule, the phone will ring with
selected distinctive ringtone. Matching rules:
Specific caller ID number. For example, 8321123;
A defined pattern with certain length using x and + to specify, where x
could be any digit from 0 to 9. Samples:
xx+ : at least 2-digit number;
xx : only 2-digit number;
[345]xx: 3-digit number with the leading digit of 3, 4 or 5;
[6-9]xx: 3-digit number with the leading digit from 6 to 9.
Alert Info text
Users could configure the matching rule as certain text (e.g., priority) and
select the custom ring tone mapped to it. The custom ring tone will be
used if the phone receives SIP INVITE with Alert-Info header in the
following format:
Alert-Info: <http://127.0.0.1>; info=priority
Selects the distinctive ring tone for the matching rule. When the incoming
caller ID or Alert Info matches the rule, the phone will ring with the selected
ring.
Ring Timeout
Defines the timeout (in seconds) for the rings on no answer. The default
setting is 60. The valid range is from 10 to 300.
Send Anonymous
If set to "Yes", the "From" header in outgoing INVITE messages will be set
to anonymous, essentially blocking the Caller ID to be displayed. The default
setting is "No".
Anonymous Call
If set to "Yes", anonymous calls will be rejected. The default setting is "No".
