FIRMWARE VERSION 1.0.0.17 GXP2140/GXP2160 USER MANUAL Page 44 of 79
 Status: Displays the Account status, Network status, and System Info of the phone;
 Account: To configure the SIP account;
 Settings: To configure call features, ring tone, audio control, LCD display, date and time, Web
services, XML applications, programmable keys and etc.;
 Network: To configure network settings;
 Maintenance: To configure web access, upgrading and provisioning, syslog, language settings,
TR-069, security and etc.;
 Phonebook: To manage Phonebook and LDAP.
STATUS PAGE DEFINITIONS
Table 13: Status Page Definitions
Status -> Account Status
Account x
Account index.
SIP User ID
Displays the configured SIP User ID.
SIP Server
Displays the configured SIP Server address.
SIP Registration
Displays SIP registration status YES/NO.
Status -> Network Status
MAC Address
Global unique ID of device, in HEX format. The MAC address will be used for
provisioning and can be found on the label coming with original box and on the
label located on the back of the device.
IP Setting
DHCP, Static IP or PPPoE.
IPv4 Address
The IPv4 address obtained on the phone.
IPv6 Address
The IPv6 address obtained on the phone.
Subnet Mask
The subnet mask obtained on the phone.
Gateway
The gateway address obtained on the phone.
DNS Server 1
The DNS server address 1.
DNS Server 2
The DNS server address 2.
PPPoE Link Up
PPPoE connection status.
NAT Type
NAT traversal status for each account.
Status -> System Info
Product Model
Product model of the phone.
Part Number
Product part number.
Software Version
 Boot: boot version number;
