FIRMWARE VERSION 1.0.0.17 GXP2140/GXP2160 USER MANUAL Page 45 of 79
Core: core version number;
Base: base version number;
Prog: program version number. This is the main firmware release number,
which is always used for identifying the software system of the phone;
Aux: Aux version number;
Dsp: DSP version number.
System up time since the last reboot.
Current system time on the phone system.
GUI and Phone service status.
Core dump file that could be downloaded for troubleshooting purpose.
ACCOUNTS PAGE DEFINITIONS
Table 14: Account Page Definitions
Account x -> General Settings
Activates/deactivates account. The default setting is "Yes".
The name associated with the SIP account.
The URL or IP address, and port of the SIP server. This is provided by your
VoIP service provider (ITSP).
The URL or IP address, and port of the SIP server. This will be used when the
primary SIP server fails.
IP address or Domain name of the Primary Outbound Proxy, Media Gateway,
or Session Border Controller. It's used by the phone for Firewall or NAT
penetration in different network environments. If a symmetric NAT is detected,
STUN will not work and ONLY an Outbound Proxy can provide a solution.
User account information, provided by your VoIP service provider (ITSP). It's
usually in the form of digits similar to phone number or actually a phone
number.
SIP service subscriber's Authenticate ID used for authentication. It can be
identical to or different from the SIP User ID.
The account password required for the phone to authenticate with the ITSP
(SIP) server before the account can be registered. After it is saved, this will
appear as hidden for security purpose.
The SIP server subscriber's name (optional) that will be used for Caller ID
display.
Allows you to access voice messages by pressing the MESSAGE button on
the phone. This ID is usually the VM portal access number. For example, in
