Grandstream Networks GXV3275 Administration Guide

Firmware Version 1.0.3.46
GXV3275 Administration Guide
Page 94 of 117
Port
It is used to configure the LDAP server port. The default LDAP port
number is 389.
Base DN
It is used to configure the LDAP search base. This is the location in the
directory where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
It is used to configure the bind "Username" for querying LDAP servers.
Some LDAP servers allow anonymous binds in which case the setting
can be left blank.
Password
It is used to configure the bind "Password" for querying LDAP servers.
The field can be left blank if the LDAP server allows anonymous binds.
LDAP Name Attributes
It is used to configure the "name" attributes of each record which are
returned in the LDAP search result. This field allows the users to
configure multiple space separated name attributes.
Example:
gn
cn sn description
LDAP Number Attributes
It is used to configure the "number" attributes of each record which are
returned in the LDAP search result. This field allows the users to
configure multiple space separated number attributes.
Example:
telephoneNumber
telephoneNumber Mobile
LDAP Mail Attributes
It is used to configure the "mail" attributes of the each record which are
returned in the LDAP search result.
Example:
mail
LDAP Name Filter
It is used to configure the filter used for name lookups.
Examples:
(|(cn=%)(sn=%)) returns all records which has the "cn" or "sn" field
starting with the entered prefix;
(!(sn=%)) returns all the records which do not have the "sn" field starting
with the entered prefix;
(&(cn=%) (telephoneNumber=*)) returns all the records with the "cn"
field starting with the entered prefix and "telephoneNumber" field set.
LDAP Number Filter
It is used to configure the filter used for number lookups.
