FIRMWARE VERSION 1.0.9.1 GXW40XX USER MANUAL Page 39 of 60
User specify the ACS password
Default is No. If set to YES, device will send inform packets to the ACS
Frequency that the inform packets will be sent out to the ACS
Connection Request
Username
Set a user name for the ACS to connect to this device
Connection Request
Password
Set a password for the ACS to connect to this device
Set a port number for the ACS to connect to this device, default is 7547
Configure the SSL authentication of Customer-premises equipment
Configure the SSL Private Key of Customer-premises equipment
Configuration option for all FXS ports ring cadence for all incoming calls.
(Syntax: c=on1/off1-on2/off2-on3/off3; [...]) Default is set to c=2000/4000; (US
standards)
Using these settings, user can configure tone frequencies according to user
preference. By default, the tones are set to North American frequencies.
Frequencies should be configured with known values to avoid uncomfortable high
pitch sounds. ONis the period of ringing (ON time in ms) while OFF is the period of
silence. In order to set a continuous ring, OFF should be zero. Otherwise it will ring
ON ms and a pause of OFF ms and then repeat the pattern.
• “Dial tone”
• “Ringback tone”
• “Busy/Re-order tone”
• “Confirmation tone”
Please refer the document below to determine your local call progress tones:
http://www.itu.int/ITU-T/inr/forms/files/tones-0203.pdf
Key pattern to get Prompt Access Tone. (Maximum 20 digits. No default)
If set to “Yes”, the configuration update via keypad is disabled.
Disables the voice prompt configuration. Default is “No”. If set to “Yes” accessing
integrated voice menu will be impossible.
Disables the Direct IP Call function. Default is “No”. If set to “Yes” direct IP-to-IP
calling will not be supported.
