P a g e | 345

UCM6200 Series User Manual

System Cleanup/Reset

Reset and Reboot

Users could perform reset and reboot under Web GUIMaintenanceSystem Cleanup/ResetReset and

Reboot.

To factory reset the device, select the mode type first. There are two different types for reset.

• User Data

All the data including voicemail, recordings, IVR Prompt, Music on Hold, CDR and backup files will be

cleared.

• All

All the configurations and data will be reset to factory default.

Figure 254: Reset and Reboot

Cleaner

Users could configure to clean the Call Detail Report/Voice Records/Voice Mails/FAX automatically under Web

GUIMaintenanceSystem Cleanup/ResetCleaner.

The following screenshot show the settings and parameters to configure the cleaner feature on UCM6200.
