56 Kayak HD — Installation and Service Manual
Section 2 — Installation
Securing Panels to Mounting Surface
When mounting the panel in a tabletop cutout, four M4 threaded holes
(two each on the left and right side of the panel) are available for securing
the panel in the cutout (
Figure 30).
Figure 30. Kayak HD Panel Mounting Holes
5 mm (0.2 in.)
panel edge to centerline
of threaded hole
8324_10_r3

GRASS VALLEY KAYAK HD Specifications

General

Keyers	4 keyers per M/E
Audio Formats Supported	AES/EBU
Input Connections	SDI, Composite, Component
Output Connections	SDI, Composite, Component
Control Interface	Ethernet
Processing	10-bit
Mix Effects (M/E)	2 M/E
