Chapter 5 - XCU menu reference
Onair Y Inp. Low/High, High/
Low, Open/High,
High/Open
Low/
High
User 0 Cradle Selects switch mode for the Yellow On Air (ISO)
signalling input.
Call Input Low/High, High/
Low, Open/High,
High/Open
Low/
High
User 0 Cradle Selects switch mode for the Call signalling input.
Signalling Outp.
Crash2Air On, Off Off Service XCU (special purpose)
Network
IP mode Auto, Manual Auto User 0 — Selects manual or automatic IP configuration
mode.
Subnet Mask 0..31 0 User 0 — Sets the subnet mask value (when manual IP
mode is selected).
BS IP digit 1 1..250 0 User 0 Cradle
Sets XCU IP address (when IP mode is manual).
BS IP digit 2 0..255 0 User 0 Cradle
BS IP digit 3 0..255 0 User 0 Cradle
BS IP digit 4 1..254 0 User 0 Cradle
CAM IP digit 1 1..250 0 User 0 Cradle
Sets camera head IP address (when IP mode is
manual).
CAM IP digit 2 0..255 0 User 0 Cradle
CAM IP digit 3 0..255 0 User 0 Cradle
CAM IP digit4 1..254 0 User 0 Cradle
Apply IP settings Exec, .... Exec User 0 — Select Exec to apply the new IP settings.
AFD
Insert On. Off Off Service XCU Turns AFD (Active Format Description)
embedding in video signal on or off.
Setting 16:9 (Full), 4:3
(Center)
16:9
(Full)
User 3 — Selects type of AFD (Active Format
Description) code to be embedded in the
video signal.
Extern Video
Aspect Ratio 16:9, 4:3 16:9 User 3 Cradle Selects aspect ratio for external video inputs.
No Signal Col.Bar, Black Col.Bar User 3 — Selects a color bar or a black frame signal is
output when no camera is connected
Video Mode 1080i50 ... — User 3 XCU Selects a video mode for the XCU test signal
when no camera is connected.
3G Output Level A, Level B Level A User 3 XCU Selects SMPTE 425M Level-A or Level-B
mapping to be used for the 3G video outputs.
HD-SDI Out D HD, SD HD User 3 XCU Selects video output signal (HD or SD) on video
connector D.
Out D Scaling 1080i, 720p 1080i User 3 XCU Selects scaler to use for output signal on video
connector D (when HD-SDI Out D = HD)
SD AspectRatio 16:9, 4:3 16:9 User 3 — Selects aspect ratio for SD outputs.
SD LetterBox Off, 16:9 Off User 3 — Selects letter box mode ratio for SD outputs.
HDSDI LensData Off, On Off Service Cradle Enable to embed lens data into HD-SDI signal.
