In the "Transmitter setting" submenu, you can set one of the follow-
ing modes in the "DSC output" line depending on the number of
functions to be transmitted: PPM10, PPM16, PPM18 and PPM24.
Default setting: PPM10.
Memory cards
Compatible memory cards
• micro SD up to 2 GB
• micro SDHC up to 32 GB
Our recommendation: For a normal use a memory card with a stor-
age capacity of up to 4 GB is sufficient.
Inserting and removing the memory card step by step
Switch off the transmitter.
The memory card slot is located in the left provided connections of
the transmitter.
To insert
Push the SD card as deep as you need to win the spring resistance of
the slot. (contacts upward)
To remove
Push the SD card slightly toward the card slot to unlock it and then
remove it.
#01
2:22h
S
L
0:00.0
0:00.0
5.5V
3.7V
M
HoTT
The included memory card is ready for use as soon as the transmit-
ter is switched on. In the display appears the symbol of a memory
card.
Otherwise, folders are created on the memory card ( represented in
the transmitter display by a permanent filling from left to right mem-
ory card). When the animation finishes, the inserted memory card is
ready for use.
You can connect the memory card to your PC by using a memory
card reader. Copy the data downloaded from the transmitter page
on the web site in the related folder of the memory card. Insert the
memory card in your transmitter.
Data recording/Data saving
The data recording in the SD card is linked to the log timer. If it is
started, the data recording starts as well and it stops when the log
timer is stopped.
The data writing on the memory card is remarked by the symbol of
the "filling" of the memory card with black from left to right.
After the installation of the memory card, there is a folder structure
in it. These folders are actually empty.
Finally, the log files are saved in subfolders called "Modelname"
named according to the structure 0001_year-month-day.bin. If a

GRAUPNER MC-28 Specifications

General

Proper use	Helicopter
Product type	Remote control
Product color	Black, Silver
Frequency band	2.4 - 2.484 GHz
Menu languages	DEU, DUT, ENG, ESP, FRE, ITA
Channels quantity	16 channels
Brand compatibility	Graupner
Throttle (TH) function	Yes
Compatible memory cards	MicroSD (TransFlash)
Number of memory records	120
Maximum operating distance	3000 m
Operating temperature (T-T)	-15 - 55 °C
Power consumption (charging)	400 mA
Operating voltage (max)	4.35 V
Operating voltage (min)	3.4 V

Weight and Dimensions

Depth	235 mm
Width	228 mm
Height	66 mm
Weight	1250 g
