Use and menu functions
Short-Cuts
The following key combinations can be used to directly call up cer-
tain menus and options:
• CLEAR
Brief simultaneous touch of the
keys or on the right four
way keys will restore the active entry field's changed parameter
value back to its default value.
• "Servo screen"
Brief simultaneous activation of the
keys of the left four-way
keys will cause a jump from the transmitter's base screen or from
almost any menu position to the "Servo display" menu,
• "Telemetry" menu
Press the center ESC key in the left four-way keys for about 1 s to
call up the "Telemetry" menu from the transmitter's base screen.
To come back to the base screen it is enough a "normal" touch
on the ESC key.
• Graphic display of telemetry data
Briefly touching one of the arrow keys of the left or right four-way
keys will cause a jump from the base screen directly to the trans-
mitter's graphic display of telemetry data or will allow paging
back and forth between individual graphic displays.
Briefly touching the ESC or SET key will cause a return back to the
base screen.
• "HIDDEN MODE"
Press and hold arrow keys
of the left four-way keys then
momentarily touch the SET key of the right four-way keys.
• Entry lock
Entry lockout is activated and deactivated from the base screen
by simultaneously pressing the ESC and SET keys for a little lon-
ger. The entry lock function is displayed by a key symbol:
The controls remain operational.
Press the ESC and ENT buttons again for about two second to
release the lock.
