GRAUPNER mx-20 Hott

292
Appendix
Graupner HoTT Smart-Box
Order No. 33700
Wide-ranging functions combined into one device make the SMART
BOX your future smart companion. Whether it comes to displaying
real-time telemetry data or settings are made on your HoTT system,
8 x 21 characters on a large display enable easy use. An integrated
sounder for the emission of an acoustic signal and warning tone
enhances the fl exible use of the BOX even further.
Using the accompanying installation set, the device can be mounted
on brackets of the transmitter and is thus optimally positioned to
enable the reading of real-time telemetry data even while controlling
your model.
The capability of user-installed updates ensures that the SMART BOX
always has the latest software and can be safely expanded with future
functions.
Transmitter voltage display with •
adjustable warning threshold
Region setting•
Range test• Signal quality•
Receiver temperature • Receiver voltage•
Servo reversal• Servo neutral position•
Servo travel• Cycle time•
Channel switching• Fail-Safe settings•
Mixer settings• Servo test•
Dimensions: approx. 76 mm x 72 mm x 17 mm (L x W x H)
Weight: approx. 55 g
RPM Magnet Sensor Graupner HoTT
Order No. 33616
RPM Optical Sensor Graupner HoTT
Order No. 33615
Graupner HoTT USB interface
Order No. 7168.6
This USB interface is required together with the separately available
adapter cable, Order No. 7168.6A, for the updating of receivers and
sensors and the mx-20 HoTT transmitter can be updated directly
with the USB cable included in the scope of delivery of the interface.
Graupner HoTT adapter cable
Order No. 7168.6A
This adapter cable is required together with the separately available
USB interface, Order No. 7168.6, for the updating of receivers and
sensors. The mx-20 HoTT transmitter can be updated directly with
the USB cable included in the scope of delivery of the interface.
