mx-24s micro-computer radio control system
Transmitter alone, with PLL Synthesizer RF module
and rechargeable transmitter battery installed, in alu-
minium case:
Order No. 4730.77 35/35B MHz band
Order No. 4748.77 40/41* MHz-Band
* 41 MHz band only approved for use in France.
Specifi cation – mx-24s transmitter
Transmission system Switchable: SPCM20, PCM20, PPM10,
PPM18, PPM 24, APCM24
Radio Frequency
section
Synthesizer (10 kHz spacing), 35 / 35B,
40 / 41 MHz band
Spot frequencies 35-MHz band: chan. 61-80, 281*, 282*
35-MHz-B band: channels 182 ... 191
40-MHz band: chan. 50 ... 59, 81 ... 92
41-MHz band: channels 400 ... 420**
Channel spacing 10 kHz
Max. control func-
tions
SPCM20 = 10, PCM20 = 10, APCM24 =
12, PPM10 = 5, PPM18 = 9, PPM24 =12
Control functions Four proportional functions with digi-
tal trims, two proportional functions, two
switched functions, two INC / DEC but-
tons
Channel pulse width 1,5 ms ± 0,5 ms
Control resolution SPCM20/APCM24: 10 Bit (1024 steps),
PCM20: 9 Bit (512 steps)
Aerial Telescopic aerial, ten sections, approx.
1150 mm long
Operating voltage 9,6 ... 12 V
Current drain approx. 85 mA (RF module removed)
150 mA (RF module switched off)
230 mA (RF module switched on)
250 mA (RF module and screen back-
light switched on)
Dimensions approx. 200 x 195 x 98 mm
Weight approx. 1100 g incl. transmitter battery
* Channels 281 and 282 not approved for use in Germany.
** 41 MHz band only approved for use in France.
* For charging the batteries you will also need the transmitter
charge lead, Order No. 3022.
** 12 V power source required.
Chargers and charge leads (optional accessories)
Order No. 6422 Minilader 2
Order No. 6427 Multilader 3
Order No. 6426 Multilader 6E*
Automatic battery chargers with special NiMH charge
programs:
Order No. 6419 Ultramat 5*, **
Order No. 6409 Ultramat 6*, **
Order No. 6410 Ultramat 10*,
Order No. 6412 Ultramat 12*, **
Order No. 6412.200 Ultramat 12*
Order No. 6414 Ultramat 14*,
Order No. 6417 Ultramat 25*, **
Order No. 6417.200 Ultramat 25*
Order No. 6416 Ultra Duo Plus 30*, **
Order No. 6425 Twin Charger
Please refer to the main GRAUPNER FS catalogue
for details of other battery chargers.
Recommended accessories
Order No. Description
70.25
Neckstrap (25 mm)
4178.1
Diagnosis lead
3290.22
Trainer / PC module
4182.9
PC interface lead
mc-22(s)/mx-22/mx-24s/PC
4185
USB PC interface
mc-22(s)/mx-22/mx-24s/PC
Replacement part
Order No. 3100.6 Telescopic transmitter aerial
Please refer to the Appendix and the main GRAUP-
NER FS catalogue for a detailed description of all
available accessories for the mx-24s radio control
set.
Description of radio control system
