GRAUPNER mx-24s - Transmitter Accessories

205
Appendix
Luxury neckstrap for hand-hand transmitters
Order No. 70.25
25 mm wide, with spring clip.
Special variable-length design.
PC interface lead
mc-22(s), mx-22 and mx-24s/PC
Order No. 4182.9
Required for communicating (copying and storing)
between
mc-22(s) / mx-22 / mx-24s transmit-
ters and an IBM-compatible PC. At the transmitter
end the Teacher / PC module, Order No. 3290.2,
is required.
The lead is supplied with the necessary software.
Diagnosis lead (DSC*)
Order No. 4178.1
This diagnosis (closed loop) lead is used to con-
nect a receiver directly to the mx-24s transmit-
ter. The action of plugging the lead into the DSC
socket on the back of the transmitter automati-
cally switches the transmitter on, but at the same
time the RF module remains disabled, so that no
signal is transmitted via the aerial. The transmit-
ter must not be switched on using the main ON /
OFF switch.
Copy lead mc-22(s)/mc-22(s), mx-22/mx-22
or mx-22/mc-22 and mx-24s/mx-24s
Order No. 4179.2
For copying between two
mc-22(s) or mx-22
transmitters, or between an mc-22(s) transmitter
and an mx-22 transmitter, or between two mx-
24s transmitters.
To connect the lead to
mx-22 and mx-24s trans-
mitters a Trainer / PC module, Order No. 3290.22,
is required in each unit. To connect it to the mc-
22(s) transmitter the interface distributor, Order
No. 4182.3 is required.
* DSC = Direct Servo Control
USB PC interface
mc-22(s), mx-22 and mx-24s/PC
Order No. 4185
Required for communicating (copying and storing)
between
mc-22(s) / mx-22 / mx-24s transmit-
ters and an IBM-compatible PC without a serial
port. At the transmitter end the Teacher / PC mo-
dule, Order No. 3290.2 is required.
The lead is supplied with the necessary software.
