Clk 1 ... 3:
“Timer” column: preset 0:00 means a count-up timer; time preset via rotary control (maximum 180 min
59 sec) generates a count-down timer (fl ashing colon in the basic display); the time is
highlighted after “zero”.
“Alarm” column: timing and sequence of warning beeps when the alarm timer approaches and passes
through zero (max. 90 sec.).
Lap counter / time table: all you have to do is assign one of the ON / OFF switches SW 1 … 7 or the momenta-
ry switch SW8. In the basic display a “Timer” appears at the same time as the “counter”.
The timer is selected and assigned separately for each fl ight phase in the »Phase set-
tings« menu, where you will also fi nd a description of the individual timers.
Mixers
• Wing mixers The revised wing mixer menu now provides for control of six-fl ap models. The range of actual functions which are
available depends on the type of model selected in the »Model type« menu.
Multi-fl ap menu: fl ight phase specifi c setting of mixer functions for the ailerons (AILE) and the two pairs of
camber-changing fl aps (FLAP = middle pair of fl aps and FL2 = inboard pair of fl aps).
AI
: in this line you set the effect of the aileron stick on the ailerons (AILE) and fl ap pairs
(FLAP, FL2).
Ail-tr: this is where you set the effect of the aileron trim on the pairs of control surfaces. The
setting is also affected by the values you have set in the »Stick mode« menu.
Diff.: aileron differential travel settings for all three pairs of control surfaces.
Fl.pos.: fl ight phase specifi c fl ap positions for all three pairs of control surfaces.
FL: in this line you determine the effect of the fl ap control, as selected in the »Transmitter
control adjust« menu, on the ailerons and fl aps.
El Fl: this linear mixer sets the effect of the fl aps when an elevator command is given; the set-
ting is usually asymmetrical.
Brake settings: the brake settings can only be set once for each model memory, and even then only if
you have selected “none” in the “Motor on C1” line of the »Model type« menu, or if “no”
has been selected for the fl ight phase concerned in the “Motor” column of the »Phase
settings« menu if you have selected “Throttle min. forward / back” in the “Motor on C1”
line.
In the »Model type« menu you can also select one of the inputs 1, 7, 8 or 9 as the con-
trol for the airbrake function. Inputs 7 and 8 can also be assigned a transmitter control in
the »Transmitter control adjust« menu, separately for each fl ight phase. The prefi xes
at the travel setting (+ or -) defi ne the direction of operation (forward or back); alterna-
tively the offset value in the “Brake” line of the »Model type« menu can be used.
