First contact
IM4 machine . 25
Technical characteristics IM4
Physical characteristics
Size mm in
W x H x D 505 x 260 x 310 20" x 10"
1/4
x 12"
3/16
Net weight kg lb
machine 9.5 21
Packaging sizes mm in
Overall size 590 x 350 x 430 23"
1/4
x 13"
3/4
x 17"
Total weight kg lb
packaging + machine 14 31
Engraving table mm in
Max. engraving area 120 x 80 4"
3/4
x 3"
5/32
Vice type Manual self centering
Jigs type Plastic
Max. dimension X,Y unlimited, 80 unlimited, 3"
5/32
Spindle/jig clearance (Z) 45 1"
3/4
Spindle travel (Z) 30 1"
3/16
Levelness < 0.12 < 0.005
Spindle
Type Rotating, top-loading
Type of spindle motor Brushless
mm in
Tool diameter 3.17 1/8
rpm
Max. spindle speed 19000
W
Spindle motor power rating 20
Engraving characteristics mm in
X,Y engraving precision 0.05 0.002
Engraving repeatability < 0.05 < 0.002
mm/s in/s
Max. X,Y,Z off-load speed 20 0.8
Max. X,Y,Z working speed 20 0.8
Sound signal according to standard ISO 11201
off-load LAeq db(A) < 60
nominal engraving LAeq db(A) < 68
nominal engraving peak Lp Cpeak db(C) < 90
