Gravotech XCOM User Manual

14
M_XCOM_EN_B
J. Connections - Installation
1. View of connectors
1
2
3
4
5
6
7
8
14
13
10
15
16
11
12
9
1. :Ethernetconnection(RJ45)
2. :USBHostconnector(x2)
3. :USBDeviceconnector:Machine/PCconnection(notavailable)
4. RS232:RS232managementconnection(Sub-D9M)
5. DEDICATEDI/O:DedicatedInputs/Outputs(Sub-D9F)
6. Power connector
7. Fuse carrier
8. On/O󰘯switch
9. ID plate
10. SAFETY:emergencystop(optional):M12(male)-12channels
11. USERI/O:GenericInputs/Outputs(Sub-D25F)
12. Safety label
13. OPTION:connection(s)foraccessory(ies):RotaryDevice(cylinderattachment):Sub-D26F-Highdensity
14. ZAXIS:Zaxis(Sub-D15F)
15. MARKING HEAD: head/CCU connecting cable
16. FIELDBUS:󰘰eldbus(optional)
