Gravotech XCOM - Input Signal Characteristics

Communication
28
M_XCOM_EN_B
23 Gnd
24 Not connected
25 Not connected
 Characteristics of the Inputs
8 non-insulated inputs are available and can be operated in positive logic.
It is possible to control the Inputs with the + 24 V internal voltage available on pins 1 and 14, and referenced
Gnd on pins 6-7-10-19-20-23.
Note
Thecurrentdeliveredbythe+24Vvoltage(pins1and14)shouldnotexceed300mA(commontoalloutputs).
• Consumption and operating range of the Inputs
- Applicable voltage per Input: 12 V - 24 V
- Intensity consumed per Input: approximately 5 mA
