E. Introduction
1. Presentation
The Control Unit is designed to manage the markings performed by the numerically controlled Heads
manufactured by Gravotech. It contains the control and power electronics, as well as a screen. The Control
Unit is the centre of the traceability system.
The Control Unit is supplied with:
• SubD9connectorwithbridging(male):Wiringofthe"Stopmarking"contact
2. Identi󰘰cationofthemarkingequipment
Themarkingequipmentisidenti󰘰edby:
• 1identi󰘰cationplateontheControlUnit
Have the model and serial number of the equipment available when contacting Gravotech.
