0716 Included Accessories

Figure 3 - 0716 Included Accessories (Compact Disc not shown)

0716 User Manual  Page 22

Antenna

Mobile Mounting

Bracket with Rubber

Feet, Rubber Washers

and Knurled Knobs

USB Cable

AC Adapter

DC Cable
