MAINTENANCE
148
2.Remove the
cover plate for
return air

a) Remove the filter
screen
b) Unscrew the fixed
screws of the return
air
3.Remove the rear
volute

Undo the buckle of the
rear and front volutes and
then remove the rear
volute away.
4. Remove the front
volute

Unscrew the fixed
screws of the front volute
and then remove it away
5.Loosen the fan
blade and fan
motor

Unscrew the fixed screws
of the fan blades and then
undo the buckle of the
motor
