Gree SUPER+ MULTI ULTRA Series User Manual

Super Free Match
Service Manual
MAINTENANCE
N
163
◆ U-Cool
GWH09UB-D3DNA1A/I; GWH12UB-D3DNA1A/I
Part list:
GWH09UB-D3DNA1A/I for CB204N00800; GWH12UB-D3DNA1A/I for CB204N01000;
No. Description
GWH09UB-D3DNA1A/I GWH12UB-D3DNA1A/I
Code Qty Code Qty
1 Front Panel Sub-Assy 2001285901 1 2001285901 1
2 Display Board 30565133 1 30565133 1
3 Screw Cover 24252024 1 24252024 1
4 Front Case Sub-assy 2001272701 1 2001272701 1
5 Filter Sub-Assy 11122134 2 11122134 2
6 Guide Louver 2 10512215 1 10512215 1
7 Louver 1054202001 6 1054202001 6
8 Crank 73012005 2 73012005 2
9 Step Motor 1521212201 1 1521212201 1
