Super Free Match
Service Manual
MAINTENANCE
164
10 Rear Case Assy 22202234 1 22202220 1
11 Rubber Plug (Water Tray) 76712012 1 76712012 1
12 Drainage Hose 05230014 1 05230014 1
13 Axile Bush Sub-assy 10542024 1 10542024 1
14 Damping Washer Sub-assy 76512011 1 76512011 1
15 Fan Bearing 76512210 1 76512210 1
16 Evaporator Support 24212128 1 24212128 1
17 Evaporator Assy 0100229401 1 01002294 1
18 Shield Board (Elbow) 01382010 1 01382010 1
19 Motor Press Plate 26112261 1 26112261 1
20 Cross Flow Fan 10352041 1 10352041 1
21 Fan Motor 15012089 1 15012089 1
22 Wall Mounting Frame 01252121 1 01252121 1
23 Pipe Clamp 26112164 1 26112164 1
24 Step Motor 1521210804 1 1521210804 1
25 Guide Louver 1 10512214 1 10512214 1
26 Electric Box Cover2 2012207524 1 2012207524 1
27 Lower Shield Sub-assy of Electric Box 01592300 1 01592300 1
28 Electric Box 2011212101 1 2011212101 1
29 Terminal Board 420111041 1 420111041 1
30 Capacitor CBB61 33010002 1 33010002 1
31 Main Board 301388701 1 301388701 1
32 Jumper 4202300102 1 4202300104 1
33 Ambient Temperature Sensor 390000453 1 390000453 1
34 Electric Box Assy 2020273811 1 2020273810 1
35 Electric Box Cover 2012213302 1 2012213302 1
36 Shield Cover of Electric Box Cover 0159230101 1 0159230101 1
37 Temperature Sensor 390000592 1 390000592 1
38 Wire Clamp 71010003 1 71010003 1
39 Remote Controller 30510135 1 30510135 1
