Super Free Match
Service Manual
MAINTENANCE
165
GWH18UC-D3DNA1A/I
Part list:
GWH18UC-D3DNA1A/I for CB204N01200
NO. Description
GWH18UC-D3DNA1A/I
Code Qty
1 Front Panel Assy 2001280401 1
2 Filter Sub-Assy 11122133 2
3 Screw Cover 24252024 3
4 Front Case Sub-assy 2001280503 1
5 Guide Louver 2 10512223 1
6 Guide Louver 1 10512222 1
7 Shaft of guide louver 1054202001 6
8 Air Louver(Manual) 10512221 3
9 Louver Clamp 26112493 3
10 Helicoid Tongue 26112495 1
11 Rear Case assy 22202472 1
12 Rubber Plug (Water Tray) 76712012 1
13 Drainage hose 0523001406 1
14 Axile Bush sub-assy 10542024 1
15 Cross Flow Fan 10352030 1
To Next Page
