Super Free Match
Service Manual
MAINTENANCE
186
10
Heat Insulation
Pipe
1220552703 1 1220552703 1 1220552703 1 1220552703 1
11 Rubber Ring 76510031 1 76510031 1 76510031 1 76510031 1
12 Rubber Ring 76510021 1 76510021 1 76510021 1 76510021 1
13 Fixed Plate 3 01844100008P 1 01844100008P 1 01844100008P 1 01844100008P 1
14
Sponge(Coping
plate)
12204437 1 12204437 1 12204437 1 12204437 1
15
Electric
Expansive
Loop
4304413215 1 4304413215 1 4304413215 1 4304413215 1
4304413216 1 4304413216 1
4304413216 1 4304413216 1
4304413217 1 4304413217 1
16
Liquid Branch
Pipe
04224100118H 1 04224100163H 1 04224211H 1 04224100161H 1
17
Branch Pipe 7
/ 0
05375200002 1
/ 0
05375200002 1
Branch Pipe 8 05375200003 1 05375200003 1
Branch Pipe 9 / 0 05375200004 1
18 Branch Pipe 2 05375200005 1 05375200005 1 05375200005 1 05375200005 1
19
Branch
Pipe(Outdoor
unit)
05375200001 1 05375200001 1 05375200001 1 05375200001 1
20 Drainage Pipe 05232046 1 05232046 1 05232046 1 05232046 1
21
Temperature
Sensor Assy
3900825301G 1 3900825301G 1 39008253G 1 39008253G 1
22
Rubber
Plug(Water
Tray)
76815214 1 76815214 1 76815214 1 76815214 1
23 Coping Plate 01264715P 1 01264715P 1 01264715P 1 01264715P 1
24 Water Tray 12504100001 1 12504100001 1 12504100001 1 12504100001 1
25 Wire Clamp 71010103 1 71010103 1 71010103 1 71010103 1
26
Gas Branch
Pipe
04224100120H 1 04574100032H 1 04614463H 1 04574100031H 1
27 Rear Side Plate 01314100032P 1 01314100060P 1 01314714P 1 01314100059P 1
28 Wire Clamp 71010003 2 71010003 2 71010003 3 71010003 3
29 Fixed Plate 2 01844100016P 1 01844100042P 1 01844100007P 1 01844100007P 1
30 Fixed Plate 1 01844100015P 1 01844100041P 1 01844100006P 1 01844100006P 1
31
Heat Insulation
Pipe
75094100009 2 75094100008 2 75094100009 3 75094100008 3
32 Sponge 12204439 1 12204439 1 12204439 1 12204439 1
33 Sponge 12204100062 1 12204100128 1 12204100061 1 12204100126 1
34 Sponge 12204100043 1 12204100127 1 12204438 1 12204100125 1
35 Sponge 12204441 1 12204441 1 12204441 1 12204441 1
36 Rear Case Assy 01284712P 1 01284100097P 1 01284712P 1 01284100097P 1
37 Sponge 12204442 1 12204442 1 12204442 1 12204442 1
38 Electric Plate 01324100047 1 01324100047 1 01324100047 1 01324100047 1
To Next Page
