Super Free Match
Service Manual
MAINTENANCE
187
FXB5A-D
Part list: FXB5A-D for EN01300140;
NO. Description
FXB5A-D
Code Qty
1 Electrical Equipment Plate 01264100017P 1
2 Electric Box Sub-assy 01324100058 1
3 Sponge 12204100052 1
4 Sponge 12204100078
5 Rear Case Assy 0128410001801P 1
6 Cable-Cross Loop 76510026 1
7 Wire Clamp 71010003 3
8 Insulation Gasket 70410524 1
9 Rubber ring 76510021 3
10 Fixed Plate 1 01844100017P 1
11 Sponge 12204100057 1
12 Sponge 12204100055 1
13 Fixed Plate 3 01844100019P 1
14 Fixed Plate 2 01844100018P 1
15 Sponge 12204100053 1
16 Sponge 12204100054 1
17 Rear Side Plate 01324100037P 1
18 Rubber Plug(Water Tray) 76815214 1
19 Coping Plate 01264100016P 1
20 Water Tray 12504100004 1
21 Gas Branch Pipe 04574100033H 1
22 Heat Insulation Pipe 1(Gas) 75094100005 1
To Next Page
