Commissioning
Commissioning gives access to the settings of the basic display including Date and Time,
Auto returns, and Alarm logbook. For details of these parameter settings, please see sec-
tion 7.1.
Calibrate Touch Panel
The touch panel requires calibration every time the user reloads the factory settings.
To calibrate select the “Calibrate touch panel” and follow the instructions on the screen,
i.e. hitting the cross hairs when they appear on the screen.
• If the touch panel is calibrated correctly, i.e. you have hit the cross hairs on the screen;
the message “Saved – hit the touch panel” will appear. Complete the calibration by
touching the panel one more time.
• If the touch panel is calibrated incorrectly, i.e. you have not hit all the cross hairs, the
display will show the message Error try again – hit the touch panel. In this case, you
must calibrate the touch panel again.
• Note that it can be useful to calibrate the touch panel using a small pointed object such
as a pencil. However, the pointed object cannot be too sharp, and you must be careful
not to push it too hard to avoid damaging the touch screen.
Service (requires an access password)
• Password level 1 is 9490. This gives you access to the analyzer configuration includ-
ing Alarm setup, Analog input/out setup, and Back-flushing setup. For details of these
settings, please see sections 7.2, 7.3, 7.4, and 7.5.
• Password level 2 gives you access to two other functions: Load factory settings and
Load default settings. For password level 2, see the Testing & Configuration Sheet de-
livered with each analyzer.
Please see Figure 1-1 for the overview of the program menu structure.
