GREEN INSTRUMENTS G36 - Specifications

Analyzer Specifications
8
2 Specifications
G36 Analyzer
Analyzer Types
• Inert Gas O
2
Analyzer
• Stack Gas O
2
Analyzer
• EGR-O
2
Analyzer
Monitors O
2
content in inert gas (N
2
or CO
2
based)
Monitors O
2
content in stack gas
Monitors O
2
content in exhaust gas recirculation
Sensor types
Zirconia sensor type SEN1 or SEN9
Measurement range
0.0%…21.0% O
2
Ambient temperature
–15°C … 55°C
Ambient humidity
Up to 100% at all relevant temperatures
Power supply
100…230 VAC – 50/60Hz
Power consumption
Max. 40 VA per analyzer – recommended fuse: 4 AT
Sample flow
0.2…8.0 l/m
Sample temperature
SEN1: ≤ 250
o
C; SEN9: ≤ 650
o
C
Sample pressure
SEN1: max.1 bar; SEN9: max. 4 bar
Digital display
Touch screen 71 x 39 mm
Output signals
Active 4…20 mA – range selectable – default 0.0…25.0%
Load output (max.)
600 ohm/24 VDC
Relays
4 relays, volt free, 24 V AC/DC, 5 A
Alarm functions
Low or High O
2
level – set points freely configurable
High-High O
2
level – set point freely configurable
System failure alarm
Response time*
90% of measuring scale in less than 45 sec. with sample flow
rate of 0.8 l/m, sample line of 1 m
Repeatability
+/– 0.1% of the measuring range
Linearity/Accuracy
+/– 0.5% of the measuring range
Drift (one month)
+/– 0.1% of the measuring range
Dimensions
17 × 20 × 9 cm (H×W×D)
Weight (analyzer only)
2.5 kg without packaging
Analyzer casing
Aluminum casing IP67
Optional: O2 analyzer with pressure compensation module, BV’s product certificate.
Specifications are subject to changes without notice.
* Response time depends on the sample flow rate and the length of the sample line.
