Configuration & Commissioning
26
7 Configuration & Commissioning
Before starting the analyzer for the first time after completing the installation,
please check and confirm that all electrical connections are installed according to the
instruction.
After switching the power on, the analyzer readings shall be stable before starting cali-
bration. It normally takes about five minutes to warm up. During the heating up of the
sensor, the Main Menu will display the oxygen content of 0.0. After several minutes,
when the sensor has reached its operation temperature, the Main Menu starts displaying
the actual oxygen content.
7.1 Setting of Basic Display Parameters
The route for setting the basic display parameters is Tools menu\Commissioning.
Figure 7-1: Basic display settings
Date and Time: The logbook and trend graph
use the calendar and clock as reference. Date
and time are per default set to follow the Coor-
dinated Universal Time (UTC). The current
time is displayed in the Graph Menu. Date and
Time can be set upon your requirement. How-
ever, it is recommended not to change date and
time too often as it will be difficult to keep track
of the historical data.
Auto return [min.]: Sets the timeout period. If
there is no action taken during that period, the
system automatically reverts to the Main Menu
from anywhere in the functional menus (except
for the Graph Menu). Default setting for auto
return is 10 minutes. Minimum setting is 1 mi-
nute.
Alarm logbook: ON/OFF mode is set here. If the Alarm logbook is ON, the alarm log-
book starts to record all of the alarms. The last 12 alarms are shown in Tools menu\Alarm
Logs. If the Alarm logbook is OFF, no alarms are saved.
