555 Electric Bender
Special Bending Information Chart
1/2 EMT Dia. = .706 Radius = 4.64 X = 2.01
Y 15 3.74 11.47 19.20 26.92 34.65 42.38 53.97 65.56 88.74 135.11
L1 15 7.72 15.45 23.18 30.90 38.63 46.36 57.95 69.54 92.72 139.09
L2 15 8.94 16.66 24.39 32.12 39.84 47.57 59.16 70.75 93.94 140.30
Z 15 10.70 18.16 25.62 33.09 40.55 48.02 59.21 70.41 92.80 137.59
MINIMUM H = 0.84
Y 22.5 1.37 6.60 11.82 17.05 22.28 27.50 35.34 43.18 58.86 90.22
L1 22.5 5.20 10.43 15.65 20.88 26.11 31.33 39.17 47.01 62.69 94.05
L2 22.5 7.02 12.25 17.48 22.70 27.93 33.16 41.00 48.83 64.51 95.87
Z 22.5 8.68 13.51 18.34 23.17 28.00 32.83 40.07 47.31 61.80 90.77
MINIMUM H = 1.48
Y 30 0.04 4.04 8.04 12.04 16.04 20.04 26.04 32.04 44.04 68.04
L1 30 7.94 11.94 15.94 19.94 23.94 29.94 35.94 47.94 71.94
L2 30 10.37 14.37 18.37 22.37 26.37 32.37 38.37 50.37 74.37
Z 30 11.42 14.89 18.35 21.82 25.28 30.48 35.67 46.07 66.85
MINIMUM H = 2.25
Y 45 1.23 4.05 6.88 9.71 12.54 16.78 21.02 29.51 46.48
L1 45 8.29 11.11 13.94 16.77 21.01 25.26 33.74 50.71
L2 45 11.93 14.76 17.59 20.42 24.66 28.90 37.39 54.36
Z 45 11.85 13.85 15.85 17.85 20.85 23.85 29.85 41.85
MINIMUM H = 4.14
Y 60 1.83 4.14 6.45 8.76 12.22 15.69 22.62 36.47
L1 60 8.74 11.05 13.36 16.82 20.29 27.21 41.07
L2 60 13.60 15.91 18.22 21.68 25.14 32.07 45.93
Z 60 11.99 13.14 14.30 16.03 17.76 21.22 28.15
MINIMUM H = 6.38
Y 90 1.00 3.00 5.00 8.00 11.00 17.00 29.00
L1 90 10.01 13.01 16.01 22.01 34.01
L2 90 17.30 20.30 23.30 29.30 41.30
Z 90 11.29 11.29 11.29 11.29 11.29
MINIMUM H = 11.29
3/4 EMT Dia. = .922 Radius = 5.54 X = 2.87
Y 15 2.35 10.07 17.80 25.53 33.26 40.98 52.58 64.17 87.35 133.71
L1 15 7.72 15.45 23.17 30.90 38.63 46.36 57.95 69.54 92.72 139.08
L2 15 9.17 16.90 24.62 32.35 40.08 47.81 59.40 70.99 94.17 140.54
Z 15 11.79 19.26 26.72 34.19 41.65 49.11 60.31 71.51 93.90 138.68
MINIMUM H = 1.12
Y 22.5 0.05 5.28 10.50 15.73 20.95 26.18 34.02 41.86 57.54 88.90
L1 22.5 5.20 10.42 15.65 20.88 26.10 31.33 39.17 47.01 62.69 94.04
L2 22.5 7.37 12.60 17.83 23.05 28.28 33.50 41.34 49.18 64.86 96.22
Z 22.5 9.90 14.73 19.56 24.39 29.22 34.04 41.29 48.53 63.02 91.99
MINIMUM H = 1.94
Y 30 2.72 6.72 10.72 14.72 18.72 24.72 30.72 42.72 66.72
L1 30 7.93 11.93 15.93 19.93 23.93 29.93 35.93 47.93 71.93
L2 30 10.83 14.83 18.83 22.83 26.83 32.83 38.83 50.83 74.83
Z 30 12.77 16.23 19.70 23.16 26.62 31.82 37.02 47.41 68.19
MINIMUM H = 2.92
Y 45 2.67 5.50 8.33 11.15 15.40 19.64 28.12 45.09
L1 45 8.25 11.08 13.90 16.73 20.97 25.22 33.70 50.67
L2 45 12.60 15.43 18.25 21.08 25.33 29.57 38.05 55.02
Z 45 13.46 15.46 17.46 19.46 22.46 25.46 31.46 43.46
MINIMUM H = 5.27
Y 60 0.33 2.64 4.95 7.26 10.72 14.18 21.11 34.97
L1 60 10.95 13.26 16.72 20.19 27.12 40.97
L2 60 16.75 19.06 22.53 25.99 32.92 46.78
Z 60 15.04 16.20 17.93 19.66 23.12 30.05
MINIMUM H = 8.03
Y 90 1.13 3.13 6.13 9.13 15.13 27.13
L1 90 12.62 15.62 21.62 33.62
L2 90 21.32 24.32 30.32 42.32
Z 90 13.95 13.95 13.95 13.95
MINIMUM H = 13.95
HEIGHT – H
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
