Greenlee 555BAT - Control Assembly - Electronic Components

Greenlee Textron / Subsidiary of Textron Inc.
44
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
555BAT™ Battery-Powered Bender
Control Assembly (cont’d)
Electronic Components
Reference Supplier Model/Part No. Description Qty.
C1,2 generic Capacitor 100ρF 50V ............................... 2
C3 generic Capacitor 47µF 50V ................................. 1
C4 generic Capacitor 4.7µF 50V ................................ 1
C5,7,8 generic Capacitor .1µF 50V .................................. 3
C6 generic Capacitor 10µF 50V ................................. 1
D1,2,3,4,5 Microsemi or equiv. 1N5242 Zener Diode 12V 500 mW........................ 5
D6 General Semiconductor FEP16BT Fast dual diode.........................................1
D7,8,9 Motorola or equiv. 1.5KE33A Transient suppressor diode ..................... 3
J1 MOLEX 39-28-1043 Connector .................................................1
J2 AMP 350711-1 Connector .................................................1
J3,4 Keystone 1287 Quick-connect male tab 1/4 x .032 .......... 2
Q1,2,3 generic 2N3904 Transistor NPN......................................... 3
Q4,5 International Rectifier IRF3205 MOSFET N-channel ................................. 2
Q6 International Rectifier IRF1010N MOSFET N-channel ................................. 1
R1 generic Resistor 100 1/4W 5% CF........................ 1
R2,3 generic Resistor 1K 1/4W 5% CF ......................... 2
R4,5,8,9,10 generic Resistor 10K 1/4W 5% CF .......................5
R6 generic Resistor 69.8K 1/4W 1% MF.................... 1
R7 generic Resistor 10K 1/4W 1% MF .......................1
R11,12,14, 15,17,18 generic Resistor 4.7K 1/4W 5% CF ...................... 6
R13,16,19 generic Resistor 15K 1/4W 5% CF ....................... 3
R20 generic Resistor 10 ohm 1/4W 5% CF ................. 1
R21 generic Resistor 100K 1/4W 5% CF .....................1
R22 Dale LVR-5-.005 Resistor .005 ohm 5W 1% ....................... 1
U1 Greenlee Textron 9186910.2 Programmed microprocessor................... 1
U2 Linear Technology LTC1255-N8 Integrated Circuit ...................................... 1
U3 Motorola or equiv. LM78L05 Voltage regulator, 5 volts ......................... 1
Y1 ECS ZTB1000J Ceramic resonator, 1 MHz ....................... 1
Miscellaneous Components
Reference Supplier Model/Part No. Description Qty.
Q4,5 Thermalloy 6221PB Heat Sink .................................................. 2
D6 AAVID 577002B04000 Heat sink .................................................. 1
Q4,5,D6 generic Screw 4–40 x 3/8 ..................................... 3
Q4,5,D6 generic Nut with captive lock washer, 4–40.......... 3
U1 generic socket, 18 PIN .......................................... 1
