555C Electric Bender Classic
Operation (cont’d)
5. Bend the conduit:
If bending 1-1/2" to 2" EMT or IMC:
a. Place one foot on the loading pedal, as shown.
Engaging the Loading Pedal
(for 1-1/2" to 2" EMT or IMC only)
If bending any other size or type of conduit:
a. Press and hold BEND.
b. Release the switch as you approach the desired
angle of bend.
c. Press BEND momentarily until the bend is
complete.
6. Press UNLOAD. The shoe will rotate backward.
Note: If bending EMT or IMC, the roller support unit
will drop to its original position.
7. Twist the conduit to release it from the hook. Remove
the conduit.
8. Press and hold UNLOAD until the shoe has rotated
back to 0°.
b. Press and hold BEND. The bender will pull up
the roller support. When the roller support
contacts the stop, remove your foot from the
loading pedal.
c. Release the switch as you approach the desired
angle of bend.
d. Press BEND momentarily until the bend is
complete.
