Greenlee / A Textron Company 9 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
555C Electric Bender Classic
BENDING CONDUIT
1. Plug the cord into an appropriate receptacle. See
Grounding Instructions.
2. Press BEND or UNLOAD until the shoe is 5° to 10°
before the 0° starting point.
3. Load the conduit so that the bending mark is aligned
with the front edge of the shoe hook, as illustrated.
Loading the Conduit
Operation
Pinch points:
Keep hands away from bending
shoe, rollers and conduit when
bender is in use.
Failure to observe this warning could
result in severe injury or death.
Do not operate the bender while wearing loose
clothing. Loose clothing can get caught in moving
parts.
Failure to observe this warning could result in
severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
flying debris.
4. See the instruction decal for the appropriate bend
angle.
