910FS Splicer
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
14
Stripping and Cleaning Fiber
Use the supplied ber stripping tool to strip the outer coating 30 to 40 mm (1.25 to 1.5
in) from its tip. Thoroughly clean the ber with alcohol-soaked (99% or greater) gauze or
lint-free tissue.
Fiber Cleaving
Do not let the ber end-face touch anything. Place the ber into the universal adapter,
and insert the adapter into the 910CL. Follow the instructions for the 910CL to cleave
the ber.
Loading Fiber into Splicer
1. Open the wind protector and install the ber adapters into the splicer, making sure
the ber is positioned into the center of the V-grooves.
2. Close the wind protector.
