Section 4. Specifications
Applicable Fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653),
NZDS/LEAF (ITU-T G.655), BIF (ITU-T G.657)
Fiber Cleaved Length 10 mm
Cladding Diameter 80-150 μm
Coating Diameter 100-1000 μm
Fiber Count Single
Fiber Aligning Method Auto Core alignment
Return Loss ≥60 dB
Actual Average Splice Loss 0.02 dB (SM), 0.01 dB (MM),
0.04 dB (DS), 0.04 dB (NZDS, LEAF, and BIF)*
Splicing Mode 60 preset/user-denable modes
Splicing Time 9 seconds in standard SM, 12 seconds in AUTO modes
Arc Calibration Mode Automatic and Manual
Protection Sleeve Length 60 mm, 40 mm and micro sleeves
Storage of Splice Results 5000 results
Tension Test 2 N
Fiber Display Magnication 240X
Tube Heating Mode 20 preset and user denable modes;
adjustable 0–240 seconds
Attenuator Mode 0.1 to 15 dB
Electrode Life 3000 splices
Splices per Battery Charge 360
Tube Heating Time 36 seconds typical
Splicing/Heating Times 250 cycles (splice/tube heat) typical
Display 5.7 inch color turn-over LCD
Connectivity RS-232/USB 2.0
Ingress Protection IP5X
Drop Test 80cm onto bottom axis
Operating Condition 0-5000 m (0-16,400 ft) above sea level; 0 to 95% RH;
-10 to 50 °C (14 to 122 °F): Maximum wind velocity of
15 m/s
Storage Condition -20 to 70 °C (-4 to 158 °F); 0 to 95% RH
Power Supply North America AC adapter (100-240 VAC);
Li battery (6600 mAh)
Weight 2.6 kg (5.72 lb) including battery
Dimensions (HxWxT) 180x160x155 mm (7.1 x 6.3 x 6.1 in)
Splice-on Connector SC, LC, FC, and ST
* Insertion loss is for cut and re-splice of identical bers.
