910FS Splicer
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
21
Explanation of Splice Modes
Mode No. Splice Mode Description
1 AUTO
For splicing in most cases; the splicer will automatically adjust splice parameters
according to ber type.
Automatic arc calibration works in this splice mode.
2 AUTO SM
For splicing standard single-mode ber (ITU-T G652).
The MFD is 9 to 10 µm at wavelength of 1310 nm.
Automatic arc calibration works in this splice mode.
3 AUTO DS
For splicing dispersion-shifted ber (ITU-T G653).
The MFD is 7 to 9 µm at wavelength of 1550 nm.
Automatic arc calibration works in this splice mode.
4 AUTO NZ
For splicing non-zero dispersion-shifted ber (ITU-T G655).
The MFD is 9 to 10 µm at wavelength of 1550 nm.
Automatic arc calibration works in this splice mode.
5 AUTO MM1
For splicing multi-mode ber (ITU-T G651). Core diameter: 50.0 to 62.5 µm.
Automatic arc calibration works in this splice mode.
6 SM
For splicing standard single-mode ber (ITU-T G652).
The MFD is 9 to 10 µm at wavelength of 1310 nm.
User can edit all parameters of this splice mode such as prefuse power, prefuse
time, arc power, arc time, align, proof test, etc.
The manual splicing operation is provided. Automatic arc calibration does not work
in this splice mode.
7 DS
For splicing dispersion-shifted ber (ITU-T G653).
The MFD is 7 to 9 µm at wavelength near 1550 nm.
User can edit all parameters of this splice mode such as prefuse power, prefuse
time, arc power, arc time, align, proof test, etc.
The manual splicing operation is provided. Automatic arc calibration does not work
in this splice mode.
8 NZ
For splicing non-zero dispersion-shifted ber (ITU-T G655).
The MFD is 9 to 10µm at wavelength of 1550 nm.
User can edit all parameters of this splice mode such as prefuse power, prefuse
time, arc power, arc time, align, proof test, etc.
The manual splicing operation is provided. Automatic arc calibration does not work
in this splice mode.
9 MM1
For splicing multi-mode ber (ITU-T G651). Core diameter: 50.0 to 62.5 µm.
User can edit all parameters of this splice mode such as prefuse power, prefuse
time, arc power, arc time, align, proof test, etc.
The manual splicing operation is provided. Automatic arc calibration does not work
in this mode.
10 AT1(SM)
User can set the attenuation value in the range of 0.1 to 15 dB.
Set the desired splice loss. If after the splice is completed the desired loss is not
achieved, the user can adjust the splicing coefcient. Increasing the coefcient will
increase the desired loss; decreasing the coefcient will reduce the splice loss.
11 SM FAST
For splicing standard single-mode ber (ITU-T G652).
The MFD is 9 to 10 µm at wavelength of 1310 nm.
It is the fastest splice mode at 9 seconds splicing time. This mode process does
not analyze ber geometry.
12~60
BLANK
(other modes)
User can assign these as their own custom splicing proles.
