910FS Splicer
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
24
Summary of electrode activation:
A
B
F
G
C D
I J
E
H
A: Cleaning Arc
B: Prefuse Time
C: Arc1 Time
D: Arc2 Time
E: Rearc Time
F: Prefuse Power
G: Arc1 Power
H: Arc2 Power
I: Arc2 ON Time
J: Arc2 OFF Time
Note: Not all settings are available in the AUTO modes.
This is a general guideline for the user to control the fusion settings. Every type of ber
has its own characteristics and properties that may require the manual setting of these
parameters. The user will have to perform careful experiments with their individual bers
to obtain optimum results.
