GreenMech CHIPMASTER 220 - Discharge Chute

CM220 Chipper 4. MACHINE PREPARATION 4-2
©GreenMechLtd 4-2 08/17
4.4 Discharge Chute (Fig 4.4)
Release swivel clamps and point chute in desired direction away from Infeed chute.
Set flap at desired height and tighten clamp.
CAUTION! Lock discharge chute in forward position
when travelling.
Fig 4.4 Discharge Chute
Swivel clam
p
s
Flap lever
