14
GETTING STARTED
AUX: There are S1, S2, S3,...,S8,S9
optional signal (0.25A max) for users to
connect to other devices such as AV signal
or camera trigger...This port is internally
connected to AUX port on the camera tray.
Connector type: JST SM10B-ZESS-TB
USB: to interface with computers or
upgradingrmware.
Connector type: Micro USB TYPE B
SBUS/PPM: To interface with SBUS/PPM
receiver.
