G0462 Wood Lathe (Mfd. Since 11/14)
-3-
Identification
Figure 1. Model G0462 identification.
Motor
Digital
Readout
Tool Rest
Bed
Live
Center
Variable
Speed Lever
Spindle
& Spur Center
Power
Switch
Head
Lock Lever
Tailstock
Handwheel
Head Pivot
Lock Pin
Tool Rest Base
w/Pivot Arm
Tailstock
Lock Lever
