Model G0505 (Mfg. since 4/04)
-31-
Head Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0505001 WING NUT M5-.8 29 P0505029 FLAT WASHER 4MM
2 P0505002 THREADED STUD M5-.8 X 50 30 P0505030 PULLEY GUARD
3 P0505003 CHIP DEFLECTOR 31 P0505031 CHAIN GUARD
4 P0505004 SPONGE PIECE 32 P0505032 PHLP HD SCR M5-.8 x 8
5 P0505005 TOP COVER 33 P0505033 INT RETAINING RING 35MM
6 P0505006 BUTTON HD CAP SCR M8-1.25 X 16 34 P0505034 BALL BEARING 6202ZZ
7 P0505007 CAP SCREW M6-1 X 16 35 P0505035 CAP SCREW M6-1 X 20
8 P0505008 LOCK WASHER 6MM 36 P0505036 TAP SCREW M6 X 20
9 P0505009 ELEVATION CRANK 37 P0505037 CHAIN SPROCKET V2.07.04
10 P0505010 HANDLE KNOB BASE 38 P0505038 CHAIN
11 P0505011 HANDLE KNOB 39 P0505039 SPACING COLLAR
12 P0505012 HANDLE SHAFT 40 P0505040 FEED ROLLER NO KEYWAY V2.07.04
13 P0505013 ROLL PIN 6 X 20 40A P0505040A FEED ROLLER W/KEYWAY V1.12.02
14 P0505014 BUSHING 41 P0505041 PHLP HD SCR M5-.8 X 10
15 P0505015 ROLLER 42 P0505042 ROLLER BRACKET
16 P0505016 GIB 43 P0505043 ROLLER BUSHING
17 P0505017 CUTTERHEAD 44 P0505044 BRACKET SPRING D10
18 P0505018 KEY 5 X 5 X 10 45 P0505045 PHLP HD SCR M4-.7 X 8
19 P0505019 SPRING D3 46 P0505046 INDICATOR
20 P0505020 KNIVES DOUBLE SIDED (2PC SET) 47 P0505047 DIRECTION LABEL
21 P0505021 GIB LOCK SCREW M6-1.0 48 P0505048 FRAME PIN
22 P0505022 BALL BEARING 6203ZZ 49 P0505049 LOCK WASHER 6MM
23 P0505023 INT RETAINING RING 40MM 50 P0505050 KNIFE GAUGE ROD
24 P0505024 CUTTERHEAD PULLEY 51 P0505051 KNIFE GAUGE
25 P0505025 HEX NUT M16-1.5 51-1 P0505051-1 COMPLETE KNIFE GAUGE ASSY
26 P0505026 RIBBED V-BELT 6 RIB/14" OD 52 P0505052 E-CLIP 9MM
27 P0505027 UPPER FRAME V1.12.02 56 P0505056 12-1/2" PLANER LABEL
27A P0505027A UPPER FRAME V2.04.04 57 P0505057 MACHINE ID LABEL
28 P0505028 PHLP HD SCR M4-.7 X 8 58 P0505058 SAFETY GLASSES LABEL
