Model G0505 (Mfg. since 4/04)
-3-
Identification
Figure 2. Model G0505 identification.
Cutterhead
Elevation Crank
Depth of
Cut Scale
Return
Rollers
Infeed
Extension
Wing
Outfeed
Extension
Wing
Cutterhead
& Motor
Assembly
Chip
Deflector
(Viewed from the rear of the machine.)
Lifting Handle
(1 of 2)
ON/OFF
Switch
