-4-
Model G0505 (Mfg. since 4/04)
The information contained herein is deemed accurate as of 1/29/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G0505
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0505 12‐1/2" PLANER
Product Dimensions:
Weight................................................................................................................................................................ 71 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................ 21-3/4 x 27-3/8 x 18-3/4 in.
Footprint (Length x Width)............................................................................................................... 20-7/8 x 10-1/2 in.
Shipping Dimensions:
Type..................................................................................................................................................... Cardboard Box
Content........................................................................................................................................................... Machine
Weight................................................................................................................................................................ 78 lbs.
Length x Width x Height....................................................................................................................... 24 x 14 x 18 in.
Must Ship Upright.................................................................................................................................................... No
Electrical:
Power Requirement........................................................................................................... 110V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 110V
Full-Load Current Rating........................................................................................................................................ 15A
Minimum Circuit Size.............................................................................................................................................. 20A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 7 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 5-15
Switch Type.................................................................................................. Toggle Safety Switch w/Removable Key
Motors:
Main
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 15A
Speed............................................................................................................................................. 19,000 RPM
Type..................................................................................................................................................... Universal
Power Transfer .................................................................................................................................. Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Main Specifications
Planer Size............................................................................................................................................. 12.5 in.
Max. Cut Width.................................................................................................................................... 12-1/2 in.
Min. Stock Length........................................................................................................................................ 6 in.
Min. Stock Thickness............................................................................................................................ 13/64 in.
Max. Stock Thickness.................................................................................................................................. 6 in.
Number of Cuts Per Inch................................................................................................................................ 52
Number of Cuts Per Minute..................................................................................................................... 20,000
Cutterhead Speed.......................................................................................................................... 10,000 RPM
Planing Feed Rate................................................................................................................................. 32 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 1/16 in.
Max. Cut Depth Planing 6-Inch Wide Board........................................................................................... 3/32 in.
