Grizzly G0505 User Manual

Model G0505 (Mfg. since 4/04)
-33-
Motor Assembly Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
100 P0505100 MOTOR ASSY W/KEYWAY V1.12.02 128 P0505128 EXT RETAINING RING 15MM
100A P0505100A MOTOR ASSY NO KEYWAY V2.07.04 129 P0505129 BALL BEARING 6002ZZ
101 P0505101 MOTOR CASING 130 P0505130 SPROCKET W/ KEYWAY V1
102 P0505102 STATOR ASSEMBLY 130V2 P0505130V2 SPROCKET NO KEYWAY V2.07.04
103 P0505103 PLATE 131 P0505131 SPACING PLATE
104 P0505104 TAP SCREW #10 X 2 3/4 132 P0505132 GEAR BOX HOUSING
106 P0505106 BALL BEARING 6201ZZ 133 P0505133 SWITCH GUARD (BLACK)
107 P0505107 ROTOR ASSEMBLY 134 P0505134 DUST GUARD PLUG
108 P0505108 BALL BEARING 6200ZZ 135 P0505135 STRAIN RELIEF
109 P0505109 MOTOR PULLEY 136 P0505136 ELECTRICAL WIRE CLAMP
110 P0505110 BRUSH HOUSING 137 P0505137 TAP SCREW M4 X 16
111 P0505111 CARBON BRUSH ASSY 138 P0505138 TAP SCREW #10 X 2
112 P0505112 THREADED BRUSH COVER 140 P0505140 FLAT WASHER 4MM
113 P0505113 SET SCREW M5-.8 X 10 142 P0505142 PHLP HD SCR M4-.7 X 8
114 P0505114 GEAR BOX COVER 145 P0505145 EXT TOOTH WASHER 5MM
115 P0505115 GEAR BOX ASSEMBLY NO KEYWAY V1.12.02 146 P0505146 TAP SCREW #10 X 2 5/16
115A P0505115A GEAR BOX HOUSING V2.07.04 148 P0505148 POSITIONING PIN
116 P0505116 GEAR SHAFT 149 P0505149 HAIRPIN COTTER PIN
117 P0505117 GEAR 70T 151 P0505151 POWER WIRES
118 P0505118 KEY 4 X 4 X 8 152 P0505152 SAFETY SWITCH
119 P0505119 BRONZE BUSHING 153 P0505153 TEMPERATURE SWITCH
120 P0505120 GEAR SHAFT 154 P0505154 TEMPERATURE SWITCH WIRE
121 P0505121 GEAR 46T 155 P0505155 PHLP HD SCR M5-.8 x 8
122 P0505122 KEY 3 X 3 X 7 156 P0505156 MOTOR LABEL
123 P0505123 BUSHING 157 P0505157 HEX NUT M10-1.5
124 P0505124 GEAR 33T 158 P0505158 GRIZZLY LABEL (COLOR)
125 P0505125 SHAFT 159 P0505159 PHLP HD SCR M6-1 X 14
126 P0505126 BALL BEARING 6202ZZ 160 P0505160 LOCK WASHER 6MM
127 P0505127 KEY 4 X 4 X 10 161 P0505161 FLAT WASHER 6MM
